Deck Width | 102″ |
Deck Length | 20’+5′ beavertail |
Deck Height | 34″ |
GVWR | 20,000 lbs |
Payload | 14,800 lbs |
Axle Rating | 2×10,000 lbs |
2024 New Model Features:
– Dexter 10k Tandem Axles
– Engineered I-Beam frame with 3″ C-channel crossmembers at 16″ centers
– Fold over max ramps can be stored in two positions: flat and upright
– Available axle options: Tandem 7,000 lbs or 10,000 lbs
Please contact us for lead time and more information.
————————
Old Model Features:
-Three axles with electric brakes
-235/80R16 wheels
-Easy lube hubs
-8” C Channel frame
-8” C Channel tongue that runs all the way to back of trailer
-3” C channel floor 16″ centers
-2 5/16″ adjustable coupler
-LED lights
-Hot dip galvanize coating
-Rub rail on sides and back of trailer
-Chain spools inside rub rails
-34” Deck height
-5’ beavertail
-Stand up ramps with spring assist
Options
-Spare tire with mount
-Galvanized toolbox
-Winch tracking with a slider every 5 feet
Warranty
3 Year – Structure and Frame Defects
5 Year – Axle System and Trailer Finish (Aluminum and Galvanized)
Trailer Type | |
---|---|
Finish | |
Deck Width | |
Deck Length | |
Deck Height | |
GVWR | |
Payload | |
Trailer Weight | |
Axle Weight Rating | |
Coupler Style | |
Coupler Size | |
Electrical Plug | |
Location |
